Description

Powerful LED downlight for your space

The Ledvance LED downlight gives you efficient lighting performance with flexible wattage and color temperature options. You benefit from high luminous output up to 3600 lumens, long service life of up to 100,000 hours, and a clean White aluminum housing that fits seamlessly into ceilings or walls.

Why this LED downlight works for you

This recessed downlight is designed to replace outdated fluorescent luminaires while providing greater efficiency and a more comfortable lighting experience. You can select between 20W, 25W, or 30W power levels as well as 3000K or 4000K color temperatures to match your application needs. Whether you want warm White for cozy reception areas or cool White for office clarity, this multi-select feature gives you real flexibility.

Main applications

Perfect for offices, conference rooms, foyers, corridors, and elevators, this LED downlight works wherever consistent, high-quality light is required. Thanks to its opal diffuser, you get very even light distribution without glare. The White aluminum housing makes it an excellent match for modern interiors.

Technical specifications

  • Ledvance LED downlight 200mm offers multi-select wattage (20W/25W/30W) and CCT options (3000K/4000K) for full flexibility.
  • Luminous flux range from 2400 to 3600 lumens ensures strong brightness for different room sizes.
  • High CRI 90 provides excellent color rendering for natural, accurate lighting impressions.
  • Opal diffuser and 100° beam angle deliver uniform light distribution with reduced glare.
  • Durable aluminum body with polycarbonate cover enhances heat dissipation and reliability.
  • Rated IP44/IP20 protection makes it suitable for indoor areas, including corridors and foyers.
  • External LED driver with power factor ≥0.90 supports stable, efficient operation.
  • Very long life of up to 100,000 hours reduces maintenance and replacement costs.
  • Safe design with RG0 photobiological rating for eye-friendly illumination.
  • Certifications include ENEC, CE, UKCA, and EAC, proving compliance with strict standards.

Why choose Ledvance

With Ledvance, you are choosing a trusted brand in LED lighting, known for quality engineering and long-lasting performance. This LED downlight provides the versatility, energy savings, and modern look you need for professional and commercial applications.

Specifications

General

Product Name
DL CMFT D200 P 30W MS 940 OP WT
Product Type
Downlight Comfort Opal
Description
Downlight luminaires with aluminum housing and high luminous efficacy
Product Code
4099854490989
Added Function
Multi Select
Features
Aluminum luminaires with 4 different cut-outs and opal diffuserVery homogenous light distributionExternal driver with Multi Lumen function of up to 5000 lmMulti Color functionConsistent lighting color ≤ 3 SDCMThrough wiring possible via additional connector box accessory
Areas of Application
Direct replacement for recessed luminaires with fluorescent lampsOffices, conference roomsReception areas, foyers, corridors, elevators

Electrical Ratings

Nominal Wattage
30 W / 25 W / 20.0 W
Nominal Voltage
220-240 V
Mains Frequency
50-60 Hz
Nominal Current
136 / 117 / 98 mA
Inrush Current
27.9 A
Inrush Current Time Th50
178 µs
Power Factor
≥ 0.90
Total Harmonic Distortion
≤ 15%
Protection Class
III
Operating Mode
External LED driver
Circuit Breaker Load
Max. Luminaires per B16 Breaker
14
Max. Luminaires per C10 Breaker
12
Max. Luminaires per C16 Breaker
20

Photometrical Characteristics

Luminous Flux
3600 lm / 3000 lm / 2400 lm
Luminous Efficacy
120 lm/W
Color Temperature
3000 K / 4000 K
Reference Control Setting
4000 K
Light Color Designation
Warm White / Cool White
Color Rendering Index (CRI Ra)
> 90
Standard Deviation of Color Matching
≤ 3 SDCM
Beam Angle
100°
Flickering Metric (Pst LM)
< 1
Stroboscope Effect Metric (SVM)
< 0.4
Photobiological Safety Group (EN62778)
RG0
Photobiological Safety Group (EN62471)
RG0

Adjustable Performance

Physical Attributes

Product Color
White
Housing Color
White
Body Material
Aluminum
Cover Material
Polycarbonate (PC)
Product Weight
530.0 g
Mercury Content
0.0 mg
Dimensions
Diameter
215.00 mm
Height
59.00 mm

Application and Mounting

Ambient Temperature Range
-20 to +40 °C
Storage Temperature Range
-20 to +80 °C
Mounting Type
Recessed
Mounting Location
Ceiling / Wall
Application Environment
Indoor
Type of Connection
Screwless terminal, 2-Pole (L, N)
Dimmable
No
Light Source Included
Yes
Light Source Replaceable
No
Mounting Dimensions
Mounting Diameter
200 mm
Mounting Width
200 mm
Mounting Depth
59 mm

Lifespan

L70/B50 at 25°C
100,000 h
L80/B10 at 25°C
70,000 h
L80/B50 at 25°C
70,000 h
L90/B10 at 25°C
40,000 h
Switching Cycles
30000

Control Gear

Recommended Control Gear
BD-PB42ML-4075
Output Current
750 / 625 / 500 mA
Output Ripple Current
≤ 10%
ECG Dimensions
Length
120 mm
Width
41 mm
Height
28.5 mm

Emergency Lighting

Type
Optional EL unit (battery and controller) for decentral operation available separately
Emergency Operation Test Type
None
Wattage in Emergency Mode
3 W
Luminous Flux in Emergency Mode
372 lm

Ratings and Certifications

IP Rating
IP44/IP20
IK Rating
IK03
Glow Wire Test
650 °C
Standards
ENEC / CE / UKCA / EAC / CB
Limited Surface Temperature 'D sign'
No
Ball Shot Safe
No
EPREL Replaceable Light Source
Not replaceable

Logistics

Single Unit
Product Code
4099854490989
Packaging Unit
Folding box
Pieces per Unit
1
Dimensions (L x W x H)
235 x 235 x 100 mm
Gross Weight
697.00 g
Volume
5.52 dm³
Shipping Case
Product Code
4099854490996
Packaging Unit
Shipping box
Pieces per Unit
8
Dimensions (L x W x H)
490 x 485 x 225 mm
Gross Weight
6648.00 g
Volume
53.47 dm³
