Ledvance LED bulkhead round 9.5W black, 3000K 4000K selectable, 1220 lumens, IP65 IK10 wall ceiling light
Ledvance LED bulkhead round 9.5W black, 3000K 4000K selectable, 1220 lumens, IP65 IK10 wall ceiling light
Ledvance LED bulkhead round 9.5W black, 3000K 4000K selectable, 1220 lumens, IP65 IK10 wall ceiling light
Ledvance LED bulkhead round 9.5W black, 3000K 4000K selectable, 1220 lumens, IP65 IK10 wall ceiling light
Ledvance LED bulkhead round 9.5W black, 3000K 4000K selectable, 1220 lumens, IP65 IK10 wall ceiling light
Ledvance LED bulkhead round 9.5W black, 3000K 4000K selectable, 1220 lumens, IP65 IK10 wall ceiling light
Ledvance LED bulkhead round 9.5W black, 3000K 4000K selectable, 1220 lumens, IP65 IK10 wall ceiling light
Ledvance LED bulkhead round 9.5W black, 3000K 4000K selectable, 1220 lumens, IP65 IK10 wall ceiling light

LED Bulkhead Round Black IP65 IK10
-
9.5W
-
1220lm
-
3000K & 4000K
-
IP 65

LV286087
Energy label
491
Stock: 30+
Expected delivery time: 7 - 9 dagen
Shipped from:
Dutch warehouse
European warehouse
  • Pay later within 30 days
  • Return up to 60 days later
  • Ordered before 7:00 PM, shipped the same day
  • Free shipping on orders over 49,-
Ledvance LED bulkhead round 9.5W black, 3000K 4000K selectable, 1220 lumens, IP65 IK10 wall ceiling light
LED Bulkhead Round Black IP65 IK10
-
9.5W
-
1220lm
-
3000K & 4000K
-
IP 65
491
  • Pay later within 30 days
  • Return up to 60 days later
  • Ordered before 7:00 PM, shipped the same day
  • Free shipping on orders over 49,-
Shopping cart

Your cart is empty

No idea where to start? Try these categories:

Total Including VAT
0
  • Pay later within 30 days
  • Return up to 60 days later
  • Ordered before 7:00 PM, shipped the same day
  • Free shipping on orders over 49,-
Description

Durable LED bulkhead for versatile lighting

The Ledvance LED bulkhead round 9.5W gives you reliable lighting for both indoor and outdoor spaces. With selectable color temperature, high lumen output, and rugged IP65 and IK10 protection, this fixture ensures strong performance in demanding environments. You get long lifespan, easy installation, and peace of mind with certified safety standards.

Why this LED bulkhead is a great choice

You can mount this round LED bulkhead on ceilings or walls, making it perfect for corridors, staircases, entrances, and outdoor areas. The polycarbonate housing withstands harsh weather and impacts, while the integrated driver ensures smooth performance without flicker. You’ll also benefit from a selectable wattage and luminous flux, letting you adapt the light to your needs.

Key features and benefits

  • Ledvance LED bulkhead round 9.5W in black finish is built for both wall and ceiling mounting, ensuring maximum installation flexibility.
  • Selectable wattage from 5.5W to 9.5W lets you choose the perfect brightness level for your application.
  • Delivers up to 1220 lumens, offering plenty of light for safety and general illumination.
  • Selectable CCT from 3000K warm white to 4000K cool white gives you control over lighting atmosphere.
  • IP65 and IK10 protection make this luminaire weatherproof and impact resistant for outdoor use.
  • Long lifespan up to 70000 hours ensures minimal maintenance and reduced replacement costs.
  • High CRI above 80 provides accurate color rendering, important for visibility and comfort.
  • Polycarbonate body and cover add strength while keeping weight low for easier handling.
  • Integrated LED driver and screwless terminal make wiring and installation quick and reliable.
  • Certified to CE, UKCA, ENEC, EAC standards for full compliance and safety assurance.

Practical applications

You can use this LED bulkhead for outdoor entrances, underground car parks, stairways, hallways, or even storage rooms. Its strong weatherproof design makes it a perfect solution for coastal areas and exposed exterior walls. Thanks to its selectable lumen settings, it serves both as a main light and as an energy-saving option for continuous use.

Specifications

General

Product Name
BLKH RD 250 P 9.5W CPS BK
Product Type
Bulkhead Round
Description
Robust wall and ceiling luminaire with IP65 and IK10 protection
Additional Function
EVERLOOP / MULTI SELECT

Electrical Ratings

Nominal Wattage
9.5 W / 8 W / 6.5 W / 5.5 W
Nominal Voltage
220-240 V
Mains Frequency
50/60 Hz
Nominal Current
42-25 mA
Inrush Current
3.44 A
Inrush Current Time (Th50)
3.284 µs
Power Factor
> 0.80
Total Harmonic Distortion
< 15%
Protection Class
II
Max Luminaires per Circuit Breaker B16
248
Max Luminaires per Circuit Breaker C10
155
Max Luminaires per Circuit Breaker C16
248

Photometric Data

Selectable Luminous Flux
1220 lm / 1070 lm / 860 lm / 710 lm
Selectable Luminous Efficacy
128 lm/W / 132 lm/W / 129 lm/W
Selectable Color Temperature
3000 K / 4000 K
Light Color
Warm White / Cool White
Color Rendering Index (Ra)
> 80
Standard Deviation of Color Matching
5 sdcm
Beam Angle
120°
Low Flicker
Yes
Flickering Metric (Pst LM)
< 1
Stroboscope Effect Metric (SVM)
< 0.4
Photobiological Safety Group
RG0

Performance Settings

Physical Attributes

Dimensions
Diameter
262.00 mm
Height
73.00 mm
Product Weight
680.00 g
Product Color
Black
Housing Color
Black
Body Material
Polycarbonate (PC)
Cover Material
Polycarbonate (PC)
Light Emitting Surface Material
Polycarbonate (PC)
Mercury Content
0.0 mg

Operating Conditions

Ambient Temperature Range
-20 to +40 °C
Storage Temperature Range
-20 to +80 °C
IP Rating
IP65
IK Rating
IK10
Application Environment
Outdoor
Mounting Type
Surface
Mounting Location
Ceiling / Wall

Control and Installation

Operating Mode
Integrated LED driver
Dimmable
No
Type of Connection
Screwless terminal
Through Wiring
Possible
Light Source Included
Yes
Replaceable Light Source
Yes, by an expert
Control Gear Output Current
350 / 300 / 250 / 200 mA
Control Gear Output Ripple Current
< 5%

Lifespan

L70/B50 at 25 °C
70000 h
L80/B10 at 25 °C
55000 h
L80/B50 at 25 °C
65000 h
L90/B10 at 25 °C
40000 h
Number of Switching Cycles
100000

Emergency Lighting

Type
EL certified driver (0Hz / DC operation) for central battery operation included
Emergency Operation Test Type
None
Wattage in Emergency Mode
9.5 W
Luminous Flux in Emergency Mode
1220 lm

Certifications and Standards

Standards
CE / CB / UKCA / EAC / ENEC / EL / EPD
Glow Wire Test
850 °C
Limited Surface Temperature (D-sign)
No
Ball Shot Safe
No
EPREL Registration
LEDV-00029-V01.01-EN

Logistical Data

Ledvance LED bulkhead round 9.5W black, 3000K 4000K selectable, 1220 lumens, IP65 IK10 wall ceiling light
LED Bulkhead Round Black IP65 IK10
-
9.5W
-
1220lm
-
3000K & 4000K
-
IP 65
